Charging for every two-wheeler and tricycle.
Outdoor charging cabinets purpose-built for electric bicycles and e-tricycles — weatherproof, fire-safe and metered per bay, so apartment blocks, delivery fleets and shared micromobility operators can charge dozens of vehicles at once.
One cabinet, a whole fleet charged overnight.
Six to ten independently metered socket bays let each vehicle charge on its own circuit, with per-bay energy metering and RFID or QR-scan activation. Rated IP65 for outdoor walls and parking sheds, with temperature and overload protection built into every bay.
- 6–10 bays of AC 220 V charging for 48 V / 60 V / 72 V battery systems.
- Per-bay metering and billing — tenants, delivery riders and residents pay only for what they use.
- Overload, leakage and over-temperature protection on every bay for fire safety.
- OCPP 2.0.1 remote monitoring so operators track sessions, faults and revenue from one dashboard.
| Bays | 6 / 8 / 10 |
|---|---|
| Input | AC 220 V, single-phase |
| Per-bay output | AC 220 V, 10 A max |
| Compatible battery | 48 V / 60 V / 72 V |
| Protection | IP65 + IK10 |
| Activation | RFID card / QR scan / App |
| Protocol | OCPP 1.6J / 2.0.1 |
| Working temp | −30 °C ~ +55 °C |
Full datasheet.
| Parameter | Specification |
|---|---|
| Model | EBC-6 / EBC-8 / EBC-10 |
| Charging bays | 6 / 8 / 10 independent sockets |
| Rated input | AC 220 V ±15%, 50/60 Hz |
| Per-bay current | 10 A maximum (adjustable) |
| Compatible battery voltage | 48 V / 60 V / 72 V DC systems |
| Metering | Per-bay energy metering (±1% class) |
| Activation | RFID / QR code / mobile App |
| Network | 4G / Wi-Fi / Ethernet |
| Protocol | OCPP 1.6J / 2.0.1 |
| Enclosure rating | IP65 + IK10, galvanized steel |
| Safety | Over-current, overload, leakage and over-temperature per bay |
| Working temperature | −30 °C ~ +55 °C |
| Standby power | < 3 W per bay |
Built for the places e-bikes actually charge.
From apartment-block sheds to delivery-company depots, the cabinet replaces the fire hazard of daisy-chained wall sockets with individually protected, metered bays.
- Residential communities — per-bay billing for tenants, no more shared-socket disputes.
- Delivery and courier fleets — overnight charging for e-bikes and e-tricycles, scheduled off-peak.
- Shared micromobility operators — track every session and fault remotely over OCPP.
- Workplace and campuses — a safe, weatherproof charging wall for staff two-wheelers.
Safety is the whole point.
E-bike battery fires make headlines — the cabinet is engineered so charging happens inside a protected, monitored enclosure, not on a hallway floor.
Quick answers.
Spec your e-bike charging cabinet.
Tell us the number of vehicles, the site and your target market — we reply with bay count, pricing and lead time within 48 hours.
